Vinyl Pool Fence Panel
Vinyl pool fence panel: 1-1/2" square pickets with pool-code compliant spacing, aluminum-reinforced bottom rail, 42" x 94" panels. 100% virgin vinyl, ASTM-tested. 1,910 m per 40HQ.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Vinyl Pool Fence Panel - 1-1/2" x 1-1/2" Square Pickets, Aluminum-Reinforced Bottom Rail
A pool fence that meets national pool codes without looking like a prison. This panel pairs a straight, routed top rail with 1-1/2" x 1-1/2" square pickets, spaced to keep small children out while preserving sightlines for supervision.
The bottom rail carries the same routed channel plus an aluminum insert for extra support across the 94" span. Standard vinyl pool fence wall posts take the rails easily, making this a sturdy, unobtrusive barrier for pool protection or clean property demarcation.
Twenty-two square pickets per panel hold the opening gaps inside the limits residential pool barrier codes typically require, which is the number that matters when an inspector walks the property. The square profile also removes the footholds a wide flat picket offers a determined climber.
The pool fence code guide covers the height, spacing, and gate rules that apply to this panel in practice.
Key Features
Pool-Code Compliant Spacing
22 square pickets per 94" panel keep openings inside typical residential pool barrier limits, blocking small children while preserving sightlines.
Climb-Resistant Square Profile
The 1-1/2" square picket offers no footholds or horizontal steps, making the panel hard to climb compared with wide flat pickets.
Aluminum-Reinforced Bottom Rail
Fitted insert keeps the ribbed bottom rail level across the full span through heat cycles, so the panel line never sags at the base.
100% Virgin Vinyl
UV-stabilised, titanium dioxide compounded into the melt. The white runs through the wall, so scratches show white on white.
Pre-Routed Assembly Kit
Pickets slide into routed top and bottom rails. No on-site routing, no special tooling, and consistent spacing every panel.
Coordinating Posts & Gates
Pre-routed 4x4 posts and 4-ft, 5-ft, and 10-ft gates complete the enclosure as one matching system.
Specifications
| Parameter | Specification |
|---|---|
| Fence Style | Square picket pool fence, flat top |
| Picket Size | 1-1/2" x 1-1/2" square, flat top - 22 pickets per panel |
| Top Rail | 2" x 3-1/2" x 94" rib rail, pre-routed (1 pc) |
| Bottom Rail | 2" x 3-1/2" x 94" rib rail, pre-routed (1 pc) |
| Bottom Reinforcement | Aluminum insert - included |
| Actual Panel Height | 42" |
| Actual Panel Width | 94" |
| Material | 100% virgin vinyl, UV-stabilised |
| Color | White (through-color) |
| Assembly | Required - panel kit ships knocked down |
| Net Weight | 19.04 kg (41.97 lbs) per panel |
| Volume | 0.067 CBM per panel |
Panel Breakdown
| Component | Dimension | Qty | Material |
|---|---|---|---|
| Pickets | 1-1/2" x 1-1/2" x 37.7" | 22 pcs | Virgin vinyl, white |
| Top rail | 2" x 3-1/2" x 94" | 1 pc | Ribbed vinyl, pre-routed |
| Bottom rail | 2" x 3-1/2" x 94" | 1 pc | Ribbed vinyl, pre-routed |
| Aluminum insert | Fitted inside bottom rail | 1 pc | Aluminum - included |
| Assembled panel | 42" H × 94" W | - | 19.04 kg net |
Posts & Gates
The panel system works with pre-routed 4x4 posts carrying the channels that receive the panel rails:
Line post
Straight runs, routes on two opposing faces.
Corner post
Two adjacent faces at 90°.
End post
One face, terminating the run.
3-way post
Three faces for T-intersections.
Coordinating gates in the same profile and finish, sharing the rail dimensions and aluminum bottom reinforcement:
4-ft single gate
Pool-side pedestrian access.
5-ft single gate
Wider pedestrian opening.
10-ft double gate
Equipment and driveway access.
Gate hardware and self-closing requirements follow the pool code in force at the property. The installation guide covers the assembly sequence for the complete fence line.
Payment & Delivery
| Term | Detail |
|---|---|
| Business Type | Manufacturer & exporter - manufactured in our own PVC production base |
| Minimum Order Quantity | 1 × 40HQ container |
| Payment Terms | 30% advance, 70% against copy of B/L at sight |
| Payment Methods | T/T, L/C |
| Delivery Time | 10–25 days after 30% advance payment |
| Packing | Plastic PE bag or pallets, per panel |
| Loading Capacity | 1,910 m per 40HQ · 785 m per 20GP (panel length) |
| Price | Consultation - volume and destination dependent |
Get the Pool Fence Quotation With a Load Plan
Panel count, post mix, gate schedule, and the loading calculation for a 40HQ or 20GP shipment-sent with the current datasheet and certificates.
