PVC Foam Board for Display
PVC foam board for display is beautiful, light in weight and simple in construction, ideally reflecting the various colors people imagine.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
PVC foam board for display can not only show natural colors, but also ideally reflect various colors that people imagine. On the whole, the surface of the board is flat and clean, looks very comfortable, and is very convenient to use.
PVC foam board has strong corrosion resistance, and its own hardness and strength are relatively large, which ensures that the board is not easily damaged and broken during use.
PVC foam board has a long service life, and its own fire-resistant and flame-retardant function can reduce the impact of fire.
TYPICAL PROPERTIES
Property | Item | Method | Unit | Value | |
Mechanical | Thickness | mm | 10-30 | ||
Density | ASTMD792 | g/cm3 | 0.55+0.03 | ||
Tensile strength | Lengthways | ASTM D638 | kg/cm3 | 110 | |
crosswise | 80 | ||||
Flexural strength | Lengthways | ASTM D790 | kg/cm3 | 240 | |
crosswise | 180 | ||||
Compressive strength | ASTM D695 | kg/cm3 | 100 | ||
Compressive stress for strain of 30% | ASTM D695 | kg/cm3 | 180 | ||
Modulus of elasticity | ASTM D638 | kg/cm3 | 10000 | ||
Hardness | ASTM D676 | Shore D | 50-80 | ||
lmpact strength(+20°C） | ASTM D256 | kg.cm/cm3 | 1.5 | ||
Thermal | Coefficient of linear thermal expansion (from-30°C to 5o°C) | ASTM D696 | mm/m°C | 0.07 | |
Heating deflection temperature | ASTM D648 | ℃ | 55 | ||
Thermal conductivity{from °C to 60℃} | DIN S2616 | w/mk | 0.03-0.07 | ||
Rate of heat transfer | DIN 52616 | w/(m2k) | 1.2-3.0 | ||
Electrical | volume resistivity | ASTM D257 | Ω.cm | 2.0×1014 | |
Surface resistance | ASTM D257 | Ω | 9.0×1014 | ||
Dielectric strength | J16911 | kv/cm | 48 | ||
others | Rw | DIN 52210/84 | dB | 35 | |
Water absorption after 7 days | ASTM D570 | % | 0.5 | ||
Fire behavior | UL-94 | / | V-0 | ||
Advantages
1. It has the properties of sound insulation, sound absorption, heat insulation and heat preservation.
2. It is safe to use, self-extinguishes without fear of fire, and is flame resistant.
3. It possesses the features of moisture-proof, mildew-proof and non-absorbent, and has strong shock-proof effect.
5. Light texture, convenient storage, transit and construction.
6.7.
8.
9.
10. The PVC foam board for display has a smooth surface and is easy to print.
 |  |
